Volvo HMF 4020 K6

Max 7.5T Max Reach 28.9M

This Volvo crane truck, equipped with the HMF 4020-K6 and extended with the FJ600-K4 fly-jib, is a precision lifting weapon. With an impressive reach of nearly 29 metres, it’s built for jobs that demand both distance and accuracy — all while remaining agile enough for urban and civil environments.

Key Features:

• Crane Model: HMF 4020-K6 with FJ600-K4 Fly-Jib
• Maximum Lifting Capacity: 7.56 tonnes @ 4.6 metres
• Maximum Horizontal Reach: 28.9 metres
• Lifting Capacity at Max Reach: 450 kg
• Hydraulic Extensions: 6 extensions on the main boom + 4 extensions on the fly-jib
• Fly-Jib Over-Bending: Up to 20°, ideal for lifting over buildings or into hard-to-reach spaces
• Radio Remote Control: Allows for safe and precise operation from the ground
• Stable & Efficient: Fitted with hydraulic outriggers for maximum stability during operation

Best Suited For:

• Installing air conditioners, switchboards, and rooftop plant
• Machinery and equipment lifts over long distances
• Civil works with access or overhead obstacles
• Construction jobs where extended reach is critical
• Urban environments and built-up sites with limited space

Certified and Site-Ready:

All our crane trucks — including this Volvo setup — are fully compliant with green sticker certifications and equipped with all required documentation to operate on major construction and infrastructure projects across Victoria.

Enquire Now Download load chart
